Measuring Range: 20 mm to 50 mm
Target: Natural objects
Repeatability: 6 µm
Linearity: ± 30 µm
Response Time: ≥ 2 ms
Output Time: ≥ 0.5 ms
Light Source: Laser, red visible light
Laser Class: 1 (IEC 60825-1:2014, EN 60825-1:2014)
Typical Light Spot Size (at 35 mm): 800 µm x 450 µm
Additional Functions:
Averaging (1 to 512x)
Automatic/manual sensitivity adjustment
Analog outputs teachable
Digital outputs teachable
Invertible digital output
Switching modes: window, distance to object, object between sensor and background
Multifunctional input (laser-off, external teach-in, trigger)
General Notes: Not free of paint wetting impairment substances.
Safety-Related Parameters:
