[2099600] SICK YM2A15-000S01FY2A4 (New) - SICK

This M12 connection cable assembly features a male 5-pin A-coded connector (head A) and two female 4-pin A-coded connectors (heads B and C), all secured with a screw-locking mechanism. Made from durable TPU, the connectors are paired with nickel-plated zinc die-cast knurled screws for added stability. The assembly is unshielded, with a current load capacity of up to 4 A, and offers high insulation resistance of 100 MΩ. With an enclosure rating of IP65, IP66K, and IP67, it ensures protection against dust and water, making it suitable for demanding industrial environments. The operating temperature range extends from -25 °C to +85 °C, and the assembly meets the UL File No. E335179 and overvoltage category III standards. Additionally, it features a rated impulse voltage of 1.5 kV and specific insulation resistance of 30 mΩ, ensuring reliable performance in harsh conditions.
