Functional Principle: Photoelectric retro-reflective sensor
Functional Principle Detail: Without reflector minimum distance (autocollimation/coaxial optics)
Sensing Range:
Min.: 0 m
Max.: 20 m
Maximum Distance from Reflector: 0 m ... 20 m
Recommended Distance: 0 m ... 12 m
Reference Reflector: P250F
Optimal Range for Best Performance: 0 mm ... 12,000 mm
Polarisation Filters: Yes
Emitted Beam:
Light Source: Laser
Type of Light: Visible red light
Light Spot Shape: Ellipse
Light Spot Size (Distance): 1.5 mm x 1.2 mm (1,000 mm)
Beam Dispersion: < +/- 1.2°
Key Laser Figures:
Normative Reference: EN 60825-1:2014, IEC 60825-1:2014
Laser Class: 1
Wavelength: 655 nm
Pulse Duration: 4 µs
Max. Pulse Power: < 2.13 mW
Average Service Life: 50,000 h
Adjustment:
Teach-In Button: BluePilot for sensitivity adjustment
IO-Link: For configuring parameters and Smart Task functions
Indication:
LED Blue: BluePilot (alignment aid)
LED Green: Operating indicator
Static on: Power on
Flashing: IO-Link mode
LED Yellow: Status of received light beam
Static on: Object not present
Static off: Object present
Flashing: Below 1.5 function reserve
Special Applications:
Detecting small objects
Detection of objects moving at high speeds
Detecting objects wrapped in film
