Housing Metric
Housing Short-body
Thread size M12 x 1
Diameter Ø 12 mm
Sensing range Sn 4 mm
Safe sensing range Sa 3.24 mm
Installation type Flush
Switching frequency 2,000 Hz
Connection type Male connector M12, 4-pin 1)
Switching output PNP
Output function NO
Electrical wiring DC 3-wire
Enclosure rating
IP68 2)
IP69K 3)
Special features Resistant against coolant lubricants, Visual adjustment indicator, IO-Link, Temperature resistance
Special applications Zones with coolants and lubricants, Mobile machines, Difficult application conditions
Items supplied Mounting nut, V2A stainless steel, with locking teeth (2x)
